PCIe x4 Expansion Kit (3500)
Includes PCIe x4 2.0 host cable adapter, PCIe x4 2.0 target cable adapter, PCIe 3.0 2-slot backplane with one PCIe x16 3.0 expansion slot, and PCIe x4 2-meter cable.
Insert the x4 host adaper card in an available slot in your server. The 3500 kit includes a PCIe Gen3 2-slot backpalne with a x16 expansion slot. With x4 adapter cards, the expansion slot in the 3500 kit suppotrs a bandwidth of 32Gb/s with x8 adpater cards. The bandwidth of any kit is only as fast as the slowest link in the chain, in this case, the PCIe x4 2.0 adapter card operating at 20Gb/s. The backplane expansion slot is x16 mechanically and electrically. So you can use x16 3.0 adapter cards with it and attain bandwidths up to 128Gb/s. The 3500 expansion kit operates with 1m, 2m, or 3m x4 PCIe cables. The backplane accepts ATX power.
PCIe x4 2.0 Host Adapter Card
|Form Factor||x4 PCIe add-in card|
|Dimensions (H x L)||2.7 x 3.1 " (68 x 78mm)|
|Front Panel Connectors||One PCIe x4 cable connector|
|Front Panel Indicators||Power On / Cable Present LEDs|
|Temperature Range||0° to 50°C (32° to 122°F)|
|Relative Humidity||10 to 90% non-condensing|
|Shock||30g acceleration peak (11ms pulse)|
|Vibration||5-17 Hz 0.5” double amplitude displacement; 7-2000Hz, 1.5g acceleration|
|Power Consumption||3.75W typical, firstname.lastname@example.orgA|
|Agency Compliance||FCC Class B • CE • RoHS|
PCIe x16 3.0 2-slot backplane
|Dimension (H x L)||2.25" x 4.5"|
|Power||ATX power supply|
|Form Facter||2 PCIe x16 slots
Target slot only accepts OSS target adapter cards.
Expansion slot accepts add-in cards up to PCIe x16 3.0
One Stop Systems warrants this product to be free of defects in material and workmanship for the warranty period purchased by the customer (1 to 5 years) from OSS beginning on the date of delivery to the original purchaser from OSS . During this period, One Stop Systems will, at its option, repair or replace this product at no additional charge to the purchaser, except as set forth in this warranty agreement. OSS will, at its option, repair or replace this product at no additional charge to the purchaser, if the defect is related to the OSS manufactured product. OSS is not liable for any defects in material or workmanship of any peripherals, products or parts, which OSS does not design or manufacture (third party products). OSS will honor the original manufacturer’s warranty on these products. One Stop Systems will analyze the defective component and the customer will be charged only in the following instances:
- No problem found: $125(U.S dollars)
- Damage Due to Negligence or Mishandling: Parts and labor at $75 per hour with a $100 minimum charge (U.S. dollars). Receipt of damaged goods voids the One Stop Systems warranty.
Repair parts and replacement products will be furnished on an exchange basis and will be either new or reconditioned. All replacement parts and products shall become the property of OSS, if such parts or products are provided under this warranty agreement. In the event a defect is not related to the OSS manufactured product or is not covered by the third party product, OSS shall repair or replace the defective parts at the purchaser’s cost and deliver the defective parts to the purchaser. This limited warranty shall not apply if the product has been misused, carelessly handled, defaced, modified or altered, or if unauthorized repairs have been attempted by others. The above warranty is the only warranty authorized by OSS and is in lieu of any implied warranties, including implied warranty of merchantability and fitness for a particular purpose. In no event will One Stop Systems be liable for any such damage as lost business, lost profits, lost savings, downtime or delay, labor, repair or material cost, injury to person or property or any similar or dissimilar consequential loss or damage incurred by the purchaser, even if OSS has been advised of the possibility of such losses or damages.
Depending on the warranty service level purchased, warranty service is obtained by advanced replacement when accompanied by a signed Warranty Service Agreement form or by delivering the product to an OSS authorized repair facility with all parts and accessories as originally shipped, along with the proof of purchase and a Returned Merchandise Authorization (RMA) number. The RMA number is obtained in advance from OSS Support or Customer Service Department and is valid for 30 days. The RMA number must be clearly marked on the exterior of the original shipping container or equivalent. Purchaser will be responsible and liable for any missing or damaged parts. Purchaser agrees to pay for shipping charges one way, and to either insure the product or assume the liability for loss or damage during transit.
Ship to: One Stop Systems
ATTENTION: RMA REPAIR DEPARTMENT
2235 Enterprise Street, Suite 110
Escondido, CA 92029
